Schneider TCSESB093F2CU0 Industrial TSN Switch | 9-Port Gigabit | PROFINET IRT | -40°C to 75°C | IP40 Rated

The Schneider Electric TCSESB093F2CU0 Industrial TSN Switch delivers deterministic communication with 9 Gigabit ports (8×RJ45 + 1×SFP). Certified for PROFINET IRT and IEEE 802.1AS time synchronization, it ensures microsecond-level precision for critical applications like motion control. Operating at -40°C to 75°C with surge/ESD protection, it guarantees reliability in harsh environments.

Model: TCSESB093F2CU0
Category: Industrial TSN Ethernet Switch
Ports: 8×10/100/1000Base-T RJ45 + 1×1000Base-X SFP
Switching Capacity: 18 Gbps
Forwarding Rate: 13.4 Mpps
Protocols: IEEE 802.1AS (gPTP), IEEE 802.1Qbv (TSN), PROFINET IRT Class B
Real-Time Performance: Cycle time ≤250μs, Jitter <1μs
Power Input: 24VDC (±20%) or 48VDC (Redundant terminals)
Power Consumption: <12W @ full load
Operating Temp.: -40°C to +75°C
Storage Temp.: -40°C to +85°C
IP Rating: IP40 (front), IP20 (terminals)
EMC Immunity: 15kV Surge/ESD, 4kV EFT
Mounting: DIN EN 60715 rail (35mm)
Dimensions (H×W×D): 45 × 136 × 106 mm
Net Weight: 0.78kg
Certifications: UL 61010-2-201, IEC 62443-4-2, SIL3 (EN 61508)
